OEM Whirlpool Washing Machine 2-Port Belt-Driven Water Drain Pump – 350365 (Pre-Owned OEM)

OEM Whirlpool Washing Machine 2-Port Belt-Driven Water Drain Pump – 350365 (Pre-Owned OEM)
$35.00
Item number: DLAP-0341

Restore rapid, complete wash water evacuation on classic belt-drive top-load washers. This authentic factory OEM dedicated 2-port mechanical drain pump operates directly from the main drive belt system beneath the tub, designed specifically for non-filter recirculation models to discharge water through the main household drain line.

  • Part Numbers: 350365 (Replaces: 285986, 350160, 350366, 358036, 358037, 358038, 362174, 362180, 367158, 370402, 536388, AP3138954, PS347731, EAP347731)

  • Condition: Pre-Owned OEM (Used)

  • Port Configuration: Dedicated 2-Port design (1 inlet, 1 outlet).

  • Drive Configuration: Mechanical belt-driven V-pulley with sealed internal bearing and shaft assembly.

  • Dimensions: 13.8 cm Length × 11.8 cm Width × 9.8 cm Height

  • Compatibility: Vintage Whirlpool, Sears Kenmore (110 series belt-drive), Roper, Estate, Inglis, and Caloric top-load washing machines.

Pro Tip: Disconnect electrical power and clamp or drain the lower tub hose before removing the old pump. Check belt alignment and tension on the motor carriage after securing the pump bracket.
